SLT-320AUR: Red Rectangular Shape SMD LED (3.0mm x 2.0mm)
|
PRODUCT DESCRIPTION |
|
|
(1) RoHs Compliant Part |
(5) Packaging: 2,000 per Reel |
|
(2) SMD Assembly or Manual
Soldering |
(6) Compact Design 1.3mm Height |
|
(3) Moisture Sensitive Component
(Level 3) |
(7) Electro-Static
Sensitive: Warm White, White, Green
& Blue |
|
(4) Bin Sorted By Color,
Intensity & Vf |
|
Electro-optical
Characteristics (Ta = 250C)
|
|
DICE MATERIAL |
VIEWING |
lD |
INTENSITY (mcd) |
FORWARD VOLTAGE |
||
|
P/N |
COLOR |
ANGLE |
Typ. (nm) |
Min. |
Max. |
Min. (V) |
Max (V) |
|
SLT-320WW |
Warm White |
125 |
3500K |
250 |
1,050 |
3.0 |
3.8 |
|
SLT-320W |
InGaN White |
5500K |
350 |
1,250 |
3.0 |
3.8 |
|
|
SLT-320B |
InGaN Blue |
465 |
250 |
500 |
3.0 |
3.8 |
|
|
SLT-320G |
InGaN Green |
525 |
350 |
1,450 |
3.0 |
3.8 |
|
|
SLT-320AUR |
AlInGaP Red |
625 |
250 |
650 |
1.7 |
2.6 |
|
|
SLT-320UY |
AlInGaP Amber |
590 |
250 |
500 |
1.7 |
2.4 |
|
Absolute Maximum
Rating (Ta = 250C)
|
Parameter |
Maximum Rating |
Units |
|
DC
Forward Current |
30 |
mA |
|
Peak
Pulse Current (1) |
100 |
mA |
|
Power
Dissipation |
100 |
mW |
|
Reverse
Voltage (IR = 10uA) |
5 |
V |
|
Operating
Temperature |
-30 to +85 |
0C |
|
Storage
Temperature |
-30 to +85 |
0C |
(1) Pulse conditions of 1/10 duty, 0.1msec pulse
width
|
