Q721JPF4D: 0.5 Watt 4-PIN
Super Flux Red LED Lamp
|
PRODUCT DESCRIPTION |
|
|
(1) RoHs Compliant Part |
(5) Bin Sorted By Color,
Intensity & Vf |
|
(2) 0.5 Watt High Lumens Output
LED Lamp |
(6) Sun Light Viewable |
|
(3) 4-PIN Package Design, Clear
5mm Len |
(7) Rugged design suitable for both indoor
& outdoor use |
|
(4) Moisture & UV Resistance
Epoxy |
|
Electro-optical Characteristics (Ta
= 250C)
|
PART NUMBER |
COLOR |
Total |
|
|
VF (V) |
LUMINOUS |
||
|
|
|
|
(nm) |
Current |
TYP. |
MAX. |
Typ. |
Max. |
|
Q721TW4D |
White |
80 |
X = 0.31 |
150 |
3.3 |
3.7 |
20 |
30 |
|
Q721TB4D |
Blue |
470 |
3.3 |
3.7 |
6 |
12 |
||
|
Q721TG4D |
Green |
525 |
3.3 |
3.7 |
20 |
40 |
||
|
Q721JPF4D |
Red |
630 |
2.0 |
2.8 |
16 |
28 |
||
|
Q721JPT4D |
Amber |
590 |
2.0 |
2.8 |
15 |
27 |
||
Absolute Maximum Rating (Ta = 250C)
|
PARAMETER |
MAXIMUM RATING |
UNITS |
|
DC Forward Current |
150 |
mA |
|
Peak Pulse Forward Current (1) |
300 |
mA |
|
Reverse Voltage (IR = 15mA) |
5 |
VR |
|
Operating Temperature |
-30 to
+85 |
0C |
|
Storage Temperature |
-40 to
+100 |
0C |
|
Lead Soldering Temperature |
2600C for 5 seconds (1.0mm or 0.63 inch from
Body) |
|
(1) Pulse Conditions of 1/10 duty
cycle max. and, or 10msec width max.
DEVICE DRAWING
Note: Polarity for Red & Amber is Reverse of
White, Blue & Green
|
LC LED Corporation |
