PRODUCT SPECIFICATION


GENERAL APPILCATIONS

►     Our PAR 30 Warm White is design as a high power spot light, ideal for:

·     Street Lighting

·     Stage (Theatre) Lighting

·     Spot Lighting in Open Areas

►     General Purpose Uses Such as

·     Illuminating Shopping Window Display Cases

·     Recess Lighting


TECHNICAL HIGHLIGHTS

►     Design as a 100W Spot Light Bulb Replacement

►     Uses 7 X 1W Power LED Emitters

►     Operating Life:  50,000 hrs

►     Operating Voltage 85VAC-260VAC

►    Low Power Consumption of 7.8W

►    Viewing Angle of 45 Degrees


PARAMETER

MIN.

TYPICAL

MAX.

Luminous Flux (Lumens)

730



1,035

Color Temperature (Kelvin) Warm White

2700



3500

Color Temperature (Kelvin) Cool White

6000



7000

Power Consumption (Watts)

7.2V



7.8V

Voltage AC (50 Hz to 60 Hz)

85



260

Operating Temperature (0C)

-20

25

40

Storage Temperature (0C)

-20

25

85

Viewing Angle (Degree)

45

Input Current (Amps)

1.75A



2.1A

Note:  Our PAR 30 Spot Light is to be use in a dry environment, ambient temperature operating range of -20C to 40C, not recommended to be use in close fixtures where the temperature may exceed 40C.



par-30

DEVICE DIAGRAM


LC LED Corporation
